STA MULTIAXIAL Products

Technology:
Made of high-performance fibers like glass, carbon and aramid, STA Multiaxial products are non-crimp stitch-bonded reinforcement materials, which provide high mechanical properties.
Advantages:

* Light weight combined with strong mechanical properties,

* Improved resin/fiber ratio, rapid and easy resin infusion,

* Reduced production time and cost, improved efficiency,

* High production process adaptability with wide product range,

* Perfect surface with high glass content.

Applications:

Used in automotive, marine, wind energy, aerospace, ballistic protection, sports equipment, construction, CTP pipes and similar fields with infusion and hand lamination molding techniques.

Products:

UniDirectional
(one axis)(0 or 90) Biaxial
(two axis)(0/90 or ±45) Triaxial
(three axis)(45/90/-45 or 0/±45) Quadraxial
(four axis)(0/45/90/-45)

0(UD)-190 0/90-340 +45/90/-45-506 0/+45/90/-45-640

0(UD)-685 0/90-1330 +45/90/-45-2000 0/+45/90/-45-670

0(UD)C-240 0/90C-320 90/+45/-45-1220 0/+45/90/-45-1000

90(UD)-180 0/90C-680 0/+45/-45-506 0/+45/90/-45-2665

90(UD)-530 +45/-45-340 0/+45/-45-825

90(UD)-675 +45/-45-475 0/+45/-45-930

90(UD)-870 +45/-45-600 0/+45/-45-2000

+45/-45-810 0/+45/-45C-920

+45/-45-1345

+45/-45C-670

+45/-45C-1220

*Can be manufactured according to customer requirements between 250 mm – 2540 mm in width and 200 g/m² - 4000 g/m² in weight.
